INTRODUCTION
Twintech design and manufacture customized process indicator for furnace industry and others sectors
Customized process indicators are electronic devices tailored to monitor and display process variables, such as temperature, pressure, or flow, in industrial environments. By integrating with various sensors, they offer real-time data visualization, enhancing process control and operational efficiency. These indicators are designed for versatility, allowing customization to fit specific requirements, including display format, scaling, and alarm settings. Their user-friendly interfaces facilitate quick adjustments and seamless integration with existing systems. Equipped with high-resolution displays, they provide clear readings in diverse lighting conditions. Advanced models often support digital communication protocols, enabling remote monitoring and data logging. This adaptability makes customized process indicators ideal for industries ranging from manufacturing to pharmaceuticals, enhancing productivity and ensuring process accuracy. Their durability and reliability make them a valuable asset in challenging environments.
Key Features :
| Round CAN Display 52.0 mm Dia |
| Very Compact size |
| Colour full Display |
| Connectivity Bluetooth |
| Rugged and can withstand extreme environments |
| Interactive user Interface for any 2 parameters |
| Waterproof IP65 |
| Panel Mount |
| Make in India |
| Supply | 230V.AC |
| Input | 4 to 20mA / 0 to 10V |
| Display | 3 & 1/2 Digits RED LED Display |
| Range | 0 to 5.00 MTR/MIN |
| Size | 48 X 96 X 110mm |
| Panel | Mounting (Black) |
| Supply | 230V.AC |
| Input | 0 to 10V |
| Display | 3 & 1/2 Digits RED LED Display |
| Range | 0 to 5.00 MTR/MIN |
| Size | 48 X 96 X 110mm |
| Panel | Mounting (Black) |
| DFWI-17010 | 48 X 96 X 110 | 0-10V DC | 0-2500 | 230V AC 50 Hz | 3 & 1/2 Red LED | Black |
| DCSI-17010 | 48 X 96 X 110 | 0-10V DC | 0-5.0 | 230V AC 50 Hz | 3 & 1/2 Red LED | Black Enclosure |
| DFQI-17010 | 48 X 96 X 110 | 0-10V DC | 0-199.9 | 230V AC 50 Hz | 3 & 1/2 Red LED | Black |
| DCSI-17420 | 48 X 96 X 110 | 4-20mA | 0-5.0 | 230V AC 50 Hz | 3 & 1/2 Red LED | Black Enclosure |
| DFQI-17420 | 48 X 96 X 110 | 4-20mA | 0-199.9 | 230V AC 50 Hz | 3 & 1/2 Red LED | Black Enclosure |
| DFWI-17420 | 48 X 96 X 110 | 4-20mA | 0-2500 | 230V AC 50 Hz | 3 & 1/2 Red LED | Black Enclosure |
